HF-242 Intelligent Fabric Packaging Machine
Depth 4015.42mm ｜ Width 5096.82mm ｜ Height 2333mm
The system features intelligent fully-automated packaging requiring no manual intervention, incorporating transverse heat-sealing and cutting with side vacuum-sealing before thermal cutting, while automatically recycling excess material. It accommodates 4-10 gauge PE packaging films, autonomously calculates fabric roll diameter and width, and includes self-regulating temperature control.
Auto-diameter Detection
Linear rail-mounted laser sensor measures roll diameter and width in real-time；Unaffected by material color or ambient light
Transverse Heat Cutter
Hard-anodized aluminum blade with solid-state relay temperature control；PTFE insulated with ≥200,000-cycle lifespan
Dual-side Vacuum
Auto-activated blower upon roll positioning
Edge Trimmer
This automatic cutting system uses heated blades to neatly trim packaging film. It finds the center of each roll by itself and cuts both sides evenly. The machine collects all scrap film automatically
Edge Shrinking
Rapid-heating Electric Heating Wire； Stainless steel high-speed blower for heat convection； Shrinks both sides of PE film
Edge Compression
Countersunk Aluminum Alloy Compression Plate；Compresses the still-hot shrink film onto the roll edges；With thermostatically controlled heating cartridge； Ensures tighter packaging
Machine Parameters
Working Width
130cm-180cm
Roll Diameter
100mm~400mm
Packaging Speed
4 rolls/min
Main Power
3-phase 380V/50Hz/15 kW；Conveyor power: Calculated/Supplied separately；Recommended cable: 5-core 6mm² RV cable (GB standard)
Air Supply
6kgf/cm²Drying Treatment（Requires Dedicated 1m³ Air Receiver），Air Compressor System11kw
Roll Weight
8kg~80kg
PE Film Thickness
0.04mm~0.10mm
Control System
PLC + HMI touchscreen
Usage Limit
Roll width + Roll diameter + Trim allowance ≤ Film width：160+40+25 ≤225；160+20+20 ≤200（Allowance increases with diameter)
